Silicone Products

項目符號 General purpose silicone sheet
項目符號 Fiberglass reinforced silicone rubber sheet
項目符號 Thermal conductive silicone
項目符號 Silicone coating
項目符號 High voltage insulator coating
項目符號 General purpose high temperature vulcanization silicone rubber


General purpose silicone sheet:

  • Product type:
    Continuous rolls or sheets
    One side embossed silicone sheet (SDN71-R1)
         NSDN71-R1  is one side embossed silicone  sheet  which
    is continuous use at temperature from -60 °C to 180 °C.
    It is chemically extremely stable and  suitable for  using with
    many acids and alkalis. Its typical applications is insulating mat,
    industrial molding (press molding, transfer molding)
    Two side embossed silicone sheet (SDN71-D1)
         SDN71-D1 is two side embossed silicone sheet which is
    continuous use at temperature from -60 C to 180 C. It is chemically extremely stable and suitable for using with many acids and alkalis. Its typical applications is insulating mat, industrial molding(press molding, transfer molding)
  • Size:
    Thickness:0.4m/m~3.0m/m
    Width: 58in (Max)

  • Properties
    Available from 40-70 durometer
    shoreA hardness
    Continuous use at -40~200°C

  • Usage:
    Insulating mat
    Industrial molding
    Furniture manufacturing




Fiberglass reinforced silicone rubber sheet:
  • Product type:
    Continuous rolls or sheet
    Two side silicone coated fabric(SP)
         SPG9A  is Two side silicone coated fabric which  is continuous use  at temperature from -60 C to 250 °C. It is chemically extremely stable and suitable for using with many acids and alkalis. Its typical applications is insulating mat, industrial molding (press molding, transfer molding)
    One side uncure silicone sheet(SH)
         SHG9A is one side uncure silicone coated
    fabric which is continuous use at
    temperature from -60 C to 250 C.  It is
    chemically extremely stable and  suitable
    for using with many acids and alkalis.  Its
    typical applications is insulating mat,
    industrial molding (press molding,
    transfer molding)
    One side cured and one side uncured


  • Size:
    Thickness:0.4m/m~3.0m/m
    Width: 48in (Max)


  • Properties
    Available from 30-70 durometer
    shore A hardness
    Continuous use at -60°~250°C


  • Usage:
    Insulating mat
    Industrial molding
    Heat pipe

top




Thermal Conductive Silicone:
  • Product type:
    Continuous rolls or sheets or grease
    Two side silicone coated fabric (ST-600)
         PowerCool®ST-600 is a composite of silicone rubber and
         fiberglass. It is specially offers high thermal conductivity.
         Size: 0.28/0.45 M/M X 30CM

       Application:

        FPD(PDP) cooling
        Switches and power supply (power transistors)
        CD-ROM and DVD (motor drive ICs)
        PC, notebook, electronic equipment( CPUs, LSis, etc)

    TFT-LCD part silicone sheet (S1-PP0)
         PowerCool®S1PP0 is silicone sheet. It  is used specially for
         the assembly of TFT-LCD module. It should uniformly distribute
         heat and pressure between the heating tool and connectors so
         that it should not cause any damage to PCB either by heat or
         pressure during the assembling process.
         Size: 0.15~0.3M/M X 30CM
         Usage: TFT-LCD
    Thermal conductive grease (TG-100)
         PowerCool®TG-100 is a nonflowable, silicone-based, high
         performance thermal conductive grease designed for the
         most demanding applications where non-electrically
         conducting grease is required. The TG-100 makes it ideal
         for situations where automatic dispensing or screen-printing
         were required.
         Usage:CPU, ICs
  • Thhermal conductivity
    Continuous use at -60°C~180°C


top


Silicone Coating:
  • Product type:
    SC-201: one part RTV
    is a high voltage insulator coating. The coating performs by
    virtue of its highly hydro-phobic water repellent nature.   It
    provides a virtually maintenance-free system to prevent
    leakage current,  tracking and flashover of porcelain, glass,
    EPDM and liquid silicone rubber insulators
  • Properties
    Resist to UV, ozone and weathering
    Good adhesion to metal, tanks, buildings
    Anti-corrosion protection

  • Usage:
    Buildings, Dam, Bridge




High Voltage Insulator Coating:
  • Product type:
    SU-101: one part RTV
    SU-101 is a high voltage insulator coating. The coating performs
    by virtue of its highly hydro-phobic water repellent nature.
    It provides a virtually maintenance-free system to prevent
    leakage current, tracking and flashover of porcelain,
    glass, EPDM and liquid silicone rubber insulators
  • Properties
    Weater repellent nature
    Preventing leakage current tracking
    and flashover

  • Usage:
    High voltage insulator




General Purpose High Temperature
      Vulcanization Silicone Rubber:
  • Product type:
    SK-110U: Silicone rubber.
         SK-110U series is general purpose silicone rubber, which compose of vinyl gum and silica powder.

  • Properties
    High temperature stability
    Low temperature flexibility
    Chemical resistance
    Weatherability
    Electrical performance

  • Usage:
    A
    utomotive
    Aviation and aerospace
    Consumer goods
    Extruded profiles
    Office equipment
    Protective equipment
    Gasket seals and molded parts
    Wire and cables




top
